RGB – Pixel – 24/48V DC Ground Light
Full-color pixel effects from below for dramatic outdoor lighting design.
Explore FeaturesOverview
Best for smart architectural pathways, events, and synchronized color play.
Product Information
Pixel-based RGB ground light that enables vibrant animated lighting with chase, pulse, and wave effects. Compatible with DMX/SPI protocols for flexible control in advanced outdoor installations.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECR187P-24/48V |
| Wattage | 7W/12W/18W/20W/24W/30W/36W |
| Input Voltage | 24/48V DC (Customized) |
| CCT | RGB |
| CRI | ≥90 |
| Beam Angle | 8°, 15°, 25°, 30°, 45°, 60° |
| Size | 60/90/120/150/200 MM (Customized) |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 , IP67 , IP68 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | DMX, ArtNET ,SPI |
| Warranty | 5 Years |
| Body Material | Aluminium/Stainless Steel |
| Installation Type | Recessed ground housing with sleeve |
