24V RGB Non Pixel LED Bar
Static RGB lighting with powerful brightness—great for bars, clubs, and feature walls.
Explore FeaturesOverview
This simple RGB bar lights up in solid or color-changing modes, without individual pixel control.
Product Information
Operating on 24V, this LED bar produces consistent RGB output using a controller for static or slow fade color changes. It’s great for cost-effective color lighting without the complexity of animation. Ideal for background walls, indoor retail setups, or entertainment rooms where basic color cycling is enough.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECR122NP-24V | Light Source | SMD5050 RGB LEDs |
| LED Quantity | 36 LEDs | Cover | Square Diffuser |
| View Angle | 120° | Pixels Control | 12 |
| Colour Mixing | RGB | Protocols | NA |
| Control Channels | NA | Address Setting | Manual |
| Input Voltage | 24V | Power Consumption | 20W/36W/40W |
| Dimensions | 750mm x 28mm x 50mm | Body Colour | Black/White |
| IP Rating | IP65, IP66 | Operating Temperature | 50°C – 60°C |
| Current | 0.60A – 0.625A/MTR | Body Type | Aluminium |
| Lifespan | 50000Hours |
