24V RGB Non Pixel LED Bar
Static RGB lighting with powerful brightness—great for bars, clubs, and feature walls.
Explore FeaturesOverview
This simple RGB bar lights up in solid or color-changing modes, without individual pixel control.
Product Information
Operating on 24V, this LED bar produces consistent RGB output using a controller for static or slow fade color changes. It’s great for cost-effective color lighting without the complexity of animation. Ideal for background walls, indoor retail setups, or entertainment rooms where basic color cycling is enough.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECR122NP-24V |
| Wattage | 14.5W/MTR |
| Input Voltage | 24V DC (Customized) |
| CCT | RGB |
| CRI | ≥90 |
| Beam Angle | 120° |
| Dimensions | 750mm x 28mm x 50mm |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | NA |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Control Channels | NA |
| Address Setting | Manual |
| LED Quantity | 36 LEDs |
| Cover | Square Diffuser |
