24V RGB – Pixel Wall Washer
Pixel RGB colors with chasing and mapping effects for event or feature lighting.
Explore FeaturesOverview
Perfect for themed architecture, entertainment venues, and animated building contours.
Product Information
This 24V pixel RGB wall washer provides addressable lighting for creative visuals, color flows, and animations. Compatible with SPI/DMX controllers, it's designed for stage designs, clubs, and vibrant architectural accents.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECR2323P-24V | Wattage | 12W/15W/18W/24W/72W |
| CCT | RGB | CRI | ≥90 |
| LED Type | SMD5050 | LED Qty | 24Pcs |
| Beam Angle | 15°, 30°, 45° | Light Output Ratio | 70% |
| Input Voltage | 24V | Body Material | Aluminium |
| Protection Rating | IP65, IP66, IP67 | Operating Temperature | 50-60°C |
| Current | 0.60A–0.625A | Protocol | DMX512,SPI,ArtNET,DALI |
| Lifespan | 50,000 Hours | Size | 1000MM (Customized) |
| Installation Type | Surface/Track/Pole/Recessed |
