48V RGB – Non-Pixel Wall Washer
Strong RGB tone coverage for large façades and commercial lighting.
Explore FeaturesOverview
Simplified RGB lighting over long runs with consistent brightness.
Product Information
This non-pixel version uses 48V for reduced power loss across longer cables, while offering 3-channel RGB color lighting. Ideal for wide entrances, logo backdrops, or general colored lighting across outdoor surfaces.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECR2323NP-48V | Wattage | 12W/15W/18W/24W/72W |
| CCT | RGB | CRI | ≥90 |
| LED Type | SMD5050 | LED Qty | 24Pcs |
| Beam Angle | 15°, 30°, 45° | Light Output Ratio | 70% |
| Input Voltage | 48V | Body Material | Aluminium |
| Protection Rating | IP65, IP66, IP67 | Operating Temperature | 50-60°C |
| Current | 0.60A–0.625A | Protocol | NA |
| Lifespan | 50,000 Hours | Size | 1000MM (Customized) |
| Installation Type | Surface/Track/Pole/Recessed |
