48V RGB – Non-Pixel Wall Washer
Strong RGB tone coverage for large façades and commercial lighting.
Explore FeaturesOverview
Simplified RGB lighting over long runs with consistent brightness.
Product Information
This non-pixel version uses 48V for reduced power loss across longer cables, while offering 3-channel RGB color lighting. Ideal for wide entrances, logo backdrops, or general colored lighting across outdoor surfaces.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECR2323NP-48V |
| Wattage | 12W/15W/18W/24W/72W |
| Input Voltage | 48V DC (Customized) |
| CCT | RGB |
| CRI | ≥90 |
| Beam Angle | 15°, 30°, 45° |
| Size | 1000MM (Customized) |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66, IP67 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | NA |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Installation Type | Surface/Track/Pole/Recessed |
| Light Output Ratio | 70% |
