48V RGB – Pixel Wall Washer
Bright, pixel-controlled RGB colors across long installations with low voltage drop.
Explore FeaturesOverview
For colorful effects over wide surfaces such as stadiums or digital sculptures.
Product Information
This 48V RGB pixel wall washer supports animated patterns, gradients, and live color changes through SPI or DMX control. Designed for commercial visuals, theme parks, or massive architectural displays.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECR2323P-48V | Wattage | 12W/15W/18W/24W/72W |
| CCT | RGB | CRI | ≥90 |
| LED Type | SMD5050 | LED Qty | 24Pcs |
| Beam Angle | 15°, 30°, 45° | Light Output Ratio | 70% |
| Input Voltage | 48V | Body Material | Aluminium |
| Protection Rating | IP65, IP66, IP67 | Operating Temperature | 50-60°C |
| Current | 0.60A–0.625A | Protocol | DMX512,SPI,ArtNET,DALI |
| Lifespan | 50,000 Hours | Size | 1000MM (Customized) |
| Installation Type | Surface/Track/Pole/Recessed |
