RGBW – Non-Pixel – 24/48V DC Flood Light
Smooth RGB color mixing with added clean white for functional lighting.
Explore FeaturesOverview
Great for architectural sites needing both mood and task lighting.
Product Information
The non-pixel RGBW variant provides balanced color + white light using 4-channel control. Designed for uniform wall washing and ambient backdrops, ideal for modern architecture or outdoor public lighting.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECRW612NP-24/48V | LED Emitter | 0.5W [5730 or 2835] |
| Output Lumens | 100-120LM Per WATT | Operational Voltage | 24/48V DC (Customized) |
| Wattage | 30W/50W/100W/150W/200W/250W/500W | Colour Temperature | RGBW |
| Beam Angle | 10°, 15°, 25°, 30°, 45°, 60°, 90°, 120° | CRI | ≥90 |
| Size | Customized | Control Type | On/Off, 0–10V/PWM dimming, DMX512/RDM |
| IP Rating | IP65, IP66, IP67 | Life Span Time | 50,000 hours |
| Protocol | NA | Shape | Rectangle / Circle |
| Housing Material | Die-cast aluminum with powder coating | Installation Type | Adjustable bracket mount/pole mount /wall mount |
