RGBW – Pixel – 24/48V DC Flood Light
Pixel-precise RGB control plus a crisp white channel for true tone scenes.
Explore FeaturesOverview
Ideal for concerts, show facades, and media buildings.
Product Information
Delivers precise RGB effects with added clarity from the dedicated white channel. Fully addressable pixel segments allow for advanced color mixing and elegant gradients across large surfaces.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECRW612P-24/48V |
| Wattage | 30W/50W/100W/150W/200W/250W/500W |
| Input Voltage | 24/48V DC (Customized) |
| CCT | RGBW |
| CRI | ≥90 |
| Beam Angle | 10°, 15°, 25°, 30°, 45°, 60°, 90°, 120° |
| Size | Customized |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66, IP67 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | DMX512,SPI,ArtNET,DALI |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Shape | Rectangle / Circle |
| Housing Material | Die-cast aluminum with powder coating |
| Installation Type | Adjustable bracket mount/pole mount /wall mount |
