24V RGBW Non Pixel LED Bar
Rich RGB with soft white output—designed for blended ambiance in interior spaces.
Explore FeaturesOverview
Enjoy the freedom of colored and white light in a simple, reliable format without the need for pixel control.
Product Information
Built to deliver high brightness and blended RGBW lighting, this 24V LED bar supports four-channel color control via a basic controller. Ideal for restaurants, cafes, and offices, it lets you switch between functional white and decorative colors without requiring addressable software or complex setups.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECRW122NP-24V |
| Wattage | 14.5W/MTR |
| Input Voltage | 24V DC (Customized) |
| CCT | RGBW |
| CRI | ≥90 |
| Beam Angle | 120° |
| Dimensions | 750mm x 28mm x 50mm |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | NA |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Control Channels | NA |
| Address Setting | Manual |
| LED Quantity | 36 LEDs |
| Cover | Square Diffuser |
