24V RGBW Non Pixel LED Panel
Balanced RGB and white output—perfect for stylish general lighting or mood setups.
Explore FeaturesOverview
A non-pixel panel that combines RGB effects and clean white, suited for ambient installations without animation needs.
Product Information
Running on 24V, this RGBW LED panel offers solid color mixing with the added benefit of true white. It can be used to toggle between functional and decorative lighting modes. Ideal for restaurants, modern reception areas, or home theaters looking for flexible, non-animated lighting.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECRW1216NP-24V |
| Wattage | 5W/4W |
| Input Voltage | 24V DC (Customized) |
| CCT | RGBW |
| CRI | ≥90 |
| Beam Angle | 120° |
| Dimensions | 300*300 , 600*600 |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | NA |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Cutting Intervals | 100MM |
| Max Length | 10-12 MTR |
| Lumens | 479 |
