24V RGBW – Pixel Wall Washer
Pixel RGBW control for deep color and pure white, suitable for dynamic wall effects.
Explore FeaturesOverview
Enables multi-zonal RGBW effects in smart, high-end architectural settings.
Product Information
This wall washer provides pixel-level RGB and white control, allowing full-scene customization and dynamic effects with pure white tones. It’s widely used in hotels, tech parks, and immersive event lighting.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECRW2323P-24V |
| Wattage | 12W/15W/18W/24W/72W |
| Input Voltage | 24V DC (Customized) |
| CCT | RGBW |
| CRI | ≥90 |
| Beam Angle | 15°, 30°, 45° |
| Size | 1000MM (Customized) |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66, IP67 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | DMX , SPI , ArtNET |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Installation Type | Surface/Track/Pole/Recessed |
| Light Output Ratio | 70% |
