Overview
Ideal for city-scale interactive lighting and branded exteriors.
Product Information
The 48V Pixel RGBW Wall Window Light supports detailed, multi-zone lighting choreography. Great for large façades, iconic architecture, or lighting designs that shift between natural white and show-stopping color movement.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECRW2312P-48V |
| Wattage | 36W/48W/60W/66W/72W/78W/84W |
| Input Voltage | 48V DC (Customized) |
| CCT | RGBW |
| CRI | ≥90 |
| Cutting Intervals | 100MM |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | DMX , SPI , ArtNET |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Max Length | 300/600/1000MM (Customized) |
| Lumens | 479 |
