RGBWW – Pixel – 24/48V DC Flood Light
Pixel RGB with dual white tones for adaptive warmth and vibrant scenes.
Explore FeaturesOverview
Tailored for smart-lighting projects, theatrical setups, or theme parks.
Product Information
With RGB and both warm + cool white control per pixel, this advanced floodlight supports fully dynamic environmental control. Built for effects-driven environments where full-spectrum flexibility is key.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECRWW612P-24/48V | LED Emitter | 0.5W [5730 or 2835] |
| Output Lumens | 100-120LM Per WATT | Operational Voltage | 24/48V DC (Customized) |
| Wattage | 30W/50W/100W/150W/200W/250W/500W | Colour Temperature | RGBWW |
| Beam Angle | 10°, 15°, 25°, 30°, 45°, 60°, 90°, 120° | CRI | ≥90 |
| Size | Customized | Control Type | On/Off, 0–10V/PWM dimming, DMX512/RDM |
| IP Rating | IP65, IP66, IP67 | Life Span Time | 50,000 hours |
| Protocol | DMX512,SPI,ArtNET,DALI | Shape | Rectangle / Circle |
| Housing Material | Die-cast aluminum with powder coating | Installation Type | Adjustable bracket mount/pole mount /wall mount |
