24V RGBWW Pixel LED Panel
Pixel-level RGB with tunable white control—ideal for complex light scenes and adaptive spaces.
Explore FeaturesOverview
Brings intelligent lighting design with full color and dual-white adjustability at a pixel level.
Product Information
This 24V RGBWW panel allows you to adjust brightness, temperature, and color effect of each pixel group, perfect for creative displays and immersive environments. Applications include museum walls, event backdrops, and wellness spaces requiring mood shifts throughout the day.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECRWW1216P-24V |
| Wattage | 5W/4W |
| Input Voltage | 24V DC (Customized) |
| CCT | RGBWW |
| CRI | ≥90 |
| Beam Angle | 120° |
| Dimensions | 300*300 , 600*600 |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | DMX , SPI , ArtNET |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Cutting Intervals | 100MM |
| Max Length | 10-12 MTR |
| Lumens | 479 |
