48V RGBWW Non Pixel LED Bar
RGB and tunable white without pixel effects—built for clean, simple, and powerful lighting environments.
Explore FeaturesOverview
Ideal for indoor or outdoor applications needing both colorful and neutral white light, without animation complexity.
Product Information
This 48V RGBWW bar offers strong output and a wide color range without addressable effects. It can switch between RGB colors and warm/cool white based on your controller. It's widely used in architectural lighting, hotel lobbies, or gallery environments, offering professional-grade lighting with minimal setup hassle.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECRWW122NP-48V | Light Source | SMD5050 RGB LEDs |
| LED Quantity | 36 LEDs | Cover | Square Diffuser |
| View Angle | 120° | Pixels Control | 12 |
| Colour Mixing | RGBWW | Protocols | NA |
| Control Channels | NA | Address Setting | Manual |
| Input Voltage | 48V | Power Consumption | 20W/36W/40W |
| Dimensions | 750mm x 28mm x 50mm | Body Colour | Black/White |
| IP Rating | IP65, IP66 | Operating Temperature | 50°C – 60°C |
| Current | 0.30A – 0.31A/MTR | Body Type | Aluminium |
| Lifespan | 50000Hours |
