48V RGBWW Non Pixel LED Bar
High-end RGBWW lighting with pixel control—suitable for showrooms, art installations, and smart
Explore FeaturesOverview
Combines full color control and dual-white tuning with long-distance power efficiency.
Product Information
The 48V RGBWW pixel bar lets you manage color, white balance, and light movement per segment. Perfect for high-end visual projects or architectural mapping, it supports smart scene creation, warm-to-cool transitions, and pixel-mapped animation across entire walls or ceilings.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECRWW122P-48V | Light Source | SMD5050 RGB LEDs |
| LED Quantity | 36 LEDs | Cover | Square Diffuser |
| View Angle | 120° | Pixels Control | 12 |
| Colour Mixing | RGBWW | Protocols | DMX , SPI , ArtNET |
| Control Channels | NA | Address Setting | Manual |
| Input Voltage | 48V | Power Consumption | 20W/36W/40W |
| Dimensions | 750mm x 28mm x 50mm | Body Colour | Black/White |
| IP Rating | IP65, IP66 | Operating Temperature | 50°C – 60°C |
| Current | 0.30A – 0.31A/MTR | Body Type | Aluminium |
| Lifespan | 50000Hours |
