48V RGBWW Non Pixel LED Bar
High-end RGBWW lighting with pixel control—suitable for showrooms, art installations, and smart
Explore FeaturesOverview
Combines full color control and dual-white tuning with long-distance power efficiency.
Product Information
The 48V RGBWW pixel bar lets you manage color, white balance, and light movement per segment. Perfect for high-end visual projects or architectural mapping, it supports smart scene creation, warm-to-cool transitions, and pixel-mapped animation across entire walls or ceilings.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECRWW122P-48V |
| Wattage | 14.5W/MTR |
| Input Voltage | 48V DC (Customized) |
| CCT | RGBWW |
| CRI | ≥90 |
| Beam Angle | 120° |
| Dimensions | 750mm x 28mm x 50mm |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | DMX , SPI , ArtNET |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Control Channels | NA |
| Address Setting | Manual |
| LED Quantity | 36 LEDs |
| Cover | Square Diffuser |
