WW – Non-Pixel – 24/48V DC Flood Light
Uniform warm white glow with consistent light spread for facades or walkways.
Explore FeaturesOverview
Suitable for outdoor environments needing calm, reliable lighting.
Product Information
A high-efficiency non-pixel floodlight designed to offer even warm white lighting. Runs safely on 24V/48V DC, with excellent heat dissipation and weatherproof housing for long-lasting illumination.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECWW612NP-24/48V | LED Emitter | 0.5W [5730 or 2835] |
| Output Lumens | 100-120LM Per WATT | Operational Voltage (VF) | 24/48V DC (Customized) |
| Wattage | 30W/50W/100W/150W/200W/250W/500W | Colour Temperature | WW |
| Beam Angle | 10°, 15°, 25°, 30°, 45°, 60°, 90°, 120° | CRI | ≥90 |
| Size | Customized | Control Type | On/Off, 0–10V/PWM dimming, DMX512/RDM |
| IP Rating | IP65, IP66, IP67 | Life Span Time | 50,000 hours |
| Protocol | NA | Shape | Rectangle / Circle |
| Housing Material | Die-cast aluminum with powder coating | Installation Type | Adjustable bracket mount/pole mount /wall mount |
