WW – Pixel – 24/48V DC Flood Light
Precision-controlled warm white light for dynamic architectural accenting.
Explore FeaturesOverview
Ideal for facades needing animated warmth and soft gradient lighting.
Product Information
This pixel-based floodlight with warm white output enables dimmable motion effects across each LED segment. Powered by 24V or 48V DC, it's perfect for smart landscapes, monuments, or feature walls requiring smooth fading or pulsing patterns.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Model | MECWW612P-24/48V | LED Emitter | 0.5W [5730 or 2835] |
| Output Lumens | 100-120LM Per WATT | Operational Voltage (VF) | 24/48V DC (Customized) |
| Wattage | 30W/50W/100W/150W/200W/250W/500W | Colour Temperature | WW |
| Beam Angle | 10°, 15°, 25°, 30°, 45°, 60°, 90°, 120° | CRI | ≥90 |
| Size | Customized | Control Type | On/Off, 0–10V/PWM dimming, DMX512/RDM |
| IP Rating | IP65, IP66, IP67 | Life Span Time | 50,000 hours |
| Protocol | DMX512,SPI,ArtNET,DALI | Shape | Rectangle / Circle |
| Housing Material | Die-cast aluminum with powder coating | Installation Type | Adjustable bracket mount/pole mount /wall mount |
