WW – Pixel – 24/48V DC Ground Light
Warm white pixel glow for animated uplighting effects in landscape design.
Explore FeaturesOverview
Perfect for gardens, driveways, and public areas needing dynamic white light.
Product Information
This pixel-controlled warm white ground light provides smooth dimming and gradient animations. Operates on 24V or 48V DC, offering smart, programmable light flow from beneath the surface with excellent weather resistance.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECWW187P-24/48V |
| Wattage | 7W/12W/18W/20W/24W/30W/36W |
| Input Voltage | 24/48V DC (Customized) |
| CCT | WW |
| CRI | ≥90 |
| Beam Angle | 8°, 15°, 25°, 30°, 45°, 60° |
| Size | 60/90/120/150/200 MM (Customized) |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 , IP67 , IP68 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | DMX, ArtNET ,SPI |
| Warranty | 5 Years |
| Body Material | Aluminium/Stainless Steel |
| Installation Type | Recessed ground housing with sleeve |
