24V Warm White Pixel LED Bar
Precise pixel control with soft warm white output—perfect for elegant indoor lighting and smart environments.
Explore FeaturesOverview
Designed for refined lighting, this pixel-enabled bar delivers smooth, controllable warm white light, ideal for automation or mood-based setups.
Product Information
This 24V warm white pixel LED bar offers addressable dimming and animation across the strip. It brings a soft, dot-free warm white glow to smart homes, lounges, or hospitality spaces. With pixel IC integration, each segment can be controlled individually, allowing smooth fades or custom effects using DMX or SPI controllers. Ideal for architectural interiors, where precise lighting matters.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECWW122NP-24V |
| Wattage | 14.5W/MTR |
| Input Voltage | 24V DC (Customized) |
| CCT | WW |
| CRI | ≥90 |
| Beam Angle | 120° |
| Dimensions | 750mm x 28mm x 50mm |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | NA |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Control Channels | NA |
| Address Setting | Manual |
| LED Quantity | 36 LEDs |
| Cover | Square Diffuser |
