24V Warm White Pixel LED Panel
Pixel-controlled warm white light for smart ceiling and architectural panel lighting.
Explore FeaturesOverview
Designed for precision-controlled white lighting, ideal for hotels, exhibitions, or smart home integration.
Product Information
This 24V warm white pixel LED panel enables dimmable segments with programmable control. Each pixel zone delivers smooth and even warm white light, allowing dynamic brightness effects and pattern animations. Perfect for high-end ceilings, ambient hospitality designs, or interactive installations.
Gallery
Downloads
Specifications Table
| Feature | Value | Feature | Value |
|---|---|---|---|
| Product Code | MECWW1216P-24V | Power Consumption | Customized |
| Cutting Intervals | 100MM | Voltage | 24V |
| Wattage/Meter | 5W/4W | Current A/M | 0.60–0.62A/MTR |
| Lumens | 479 | Operating Temperature | 50°–60° C |
| Colour Temperature | WW | Max Length | 10–12 MTRS |
| Protocol | DMX , SPI , ArtNET | LED Source | 5050 |
| LED Life Time | 50,000 Hrs | IP Rating | IP65, IP66 |
| Size | 300*300MM , 600*600MM | Pixel | 10MTR |
| CRI | ≥90 |
