48V Warm White Non Pixel LED Panel
High-efficiency warm lighting for uniform coverage in large spaces or installations.
Explore FeaturesOverview
48V operation ensures long cable runs with steady warm lighting performance.
Product Information
This non-pixel panel offers consistent warm white output powered by 48V DC, making it ideal for installations that span multiple panels. No controller needed—just reliable white light for workspaces, hallways, or public buildings.
Gallery
Downloads
Specifications
| Feature | Value |
|---|---|
| Model | MECWW1216NP-48V |
| Wattage | 5W/4W |
| Input Voltage | 48V DC (Customized) |
| CCT | WW |
| CRI | ≥90 |
| Beam Angle | 120° |
| Dimensions | 300*300 , 600*600 |
| Led Make | CREE / BLX / LUMI / OSRAM |
| LED Source | 5050 |
| Operating Temperature | 45°-50°C |
| Burning Hours | 40,000 + hours |
| IP Rating | IP65, IP66 |
| Driver | FULLHAM/PHILIPS/BAG |
| Protocol | NA |
| Warranty | 5 Years |
| Body Material | Aluminium |
| Current | 0.60A – 0.625A/MTR |
| Cutting Intervals | 100MM |
| Max Length | 10-12 MTR |
| Lumens | 479 |
